These models are designed for surge and Hi-Pot testing of motors, generators, stators, transformers, coils and other high-voltage windings, helping detect insulation weaknesses and winding faults before equipment failure.
The primary difference is the maximum testing voltage. The VM10KHR supports testing up to 10KV, the VM12KHR up to 12KV, and the VM15KHR up to 15KV for higher-voltage winding applications.
Yes. All three models combine Digital Surge Testing and Hi-Pot Testing in a single platform, allowing comprehensive insulation evaluation and winding analysis.
Yes. Advanced waveform comparison technology helps identify turn-to-turn shorts, insulation deterioration and winding defects that may not be visible through conventional electrical tests.
These models combine surge testing and Hi-Pot testing in one instrument, providing precise fault detection, comprehensive insulation evaluation, advanced reporting capabilities and reliable performance for critical electrical testing applications.
Ensure accurate fault detection, insulation verification, and quality assurance for motors, generators, transformers, and high-voltage windings with the VM10KHR, VM12KHR, and VM15KHR series.
✔ Surge & Hi-Pot Testing in One Platform
✔ Advanced Waveform Analysis
✔ Automatic Report Generation
✔ High-Voltage Testing up to 15KV
✔ Expert Technical Support
Get pricing, technical specifications, application guidance, and expert recommendations from the Vivid Metrawatt team.
